StarEFX™ Pool Lighting Kit

A light show of color-changing and shining, twinkling stars that will amaze any family member or friend. Whether entertaining guests for a swim in the pool or acting as a lighting backdrop over a BBQ, the ambient lighting will set the mood for the evening.

With StarEFX™ Pool Lighting Kits, fiber star points are laid throughout the pool floor or walls. Light is transmitted from an external light source to the many individual fiber stars. Emitting only light with no heat or electricity in the fiber cable, the light source 'illuminator' is powered by LEDs with up to 30,000 hours of life. This means there is little chance of lamp replacement, making this the best choice in lighting as an extremely low-maintenance option.

Fiber star points are fixed onto the concrete pool shell before tiling. Each fiber star point is encased in a fiber enclosure that comes in two sizes to fit 20mm mosaic tiles or 50mm tiles.

Note: conduits must be installed during the concrete form works for the fiber cables to be threaded from the illuminator's location.

Another benefit of the StarEFX™ pool lighting kit is it can be integrated with home automation devices that enable you with total control to customize your “mood”. Customize your pool, spa, sauna, or steam room, you pick the colors and choose the dimming scale, everything you need to really set the vibe!

Applications
Swimming pools - Spas - Sauna - Steam room - Ponds

Functions
6 colored wheel with twinkle effect - Single color can be selected - Color change speed is adjustable - Twinkle on/off selection - Dimming - Wireless remote operation

Options
- Custom-sized lengths to your requirements.
- Home automation integration with optional DMX interface
*Note: Other automation systems, such as CBUS and Dynalite, will require their own DMX gateway module.

As standard kits we offer 5 fibre star points per sqm or 10.76 sqft
	Pool dimensions		Pool area size		Tail length from illuminator to pool
KIT	M	FT	SM / SQFT	Fiber star points	M / FT
StarEFX-70	4 x 4	6.5 x 23	16 / 172	70	12 / 39
StarEFX -90	5 x 4	9.8 x 19.6	20 / 215	90	12 / 39
StarEFX -120	6 x 4	19.6 x 13	24 / 258	120	12 / 39
StarEFX -140	7 x 4	23 x 13	28 / 301	140	12 / 39
StarEFX -160	8 x 4	26.2 x 13	32 / 344	160	12 / 39
StarEFX -180	9 x 4	29.5 x 13	36 / 387	180	12 / 39
StarEFX -200	10 x 4	32.8 x 13	40 / 430	200	12 / 39
For custom projects and designs add details here:

Warranty Information:

12 month illuminator warranty
